孔用格来圈GB／T15242．1-94及GB/T15242.3-95标准
产品详细介绍：

适用工况
工作压力：≤60MPa
往复速度：≤下5m／S
使用温度：-35～+200℃(取决于O形圈的材料)
工作介质：液压油、汽、水
参考标准
符合IS07425/1标准。符合GB／T15242．1-94及GB/T15242.3-95标准，通用于B+L的GS55044、GS55042、GS55046及B+L的PG44、PG42、PG46系列。
产品号缸径槽底径槽宽R1GB/T15242,1-94代号通用编号DH9dh9L+0.2MaxB+LB+S
|
|
| GSFO080 |
8 |
3.1 |
2.2 |
0.4 |
TF0080 |
GS55044-0080 |
PG440-0080 |
| GSF0100 |
10 |
5,1 |
2.2 |
0,4 |
TF0010 |
GS55044-0100 |
PG440-0100 |
| GSFO140 |
14 |
9.1 |
2.2 |
0.4 |
TF0140 |
GS55044-0140 |
PG440-0140 |
| GSF0150L |
15 |
10.1 |
2.2 |
0.4 |
TF0150 |
GS55044-0150 |
PG460-0150 |
| GSFO150 |
15 |
7,5 |
2.2 |
0,4 |
TF0150B |
GS55044-0150 |
PG440-0150 |
| GSF0160L |
16 |
11,1 |
2.2 |
0.4 |
TF0160 |
GS55046-0160 |
PG460-0160 |
| GSFO160 |
16 |
8.5 |
3.2 |
0.4 |
TF0160B |
GS55044-0160 |
PG440-0160 |
| GSF0180L |
18 |
13.1 |
2.2 |
0.4 |
TF0180 |
GS55046-0180 |
PG460-0180 |
| GSFO180 |
18 |
10.5 |
3.2 |
0.4 |
TF0180B |
GS55044-0180 |
PG440-0180 |
| GSF0200L |
20 |
15.1 |
2.2 |
0.4 |
TF0200 |
GS55046-0200 |
PG460-0200 |
| GSF0200 |
20 |
12.5 |
3.2 |
0.4 |
TF0200B |
GS55044-0200 |
PG440-0200 |
| GSF0240L |
24 |
19,1 |
2.2 |
0.4 |
TF0240 |
GS55046-0240 |
PG460-0240 |
| GSF0240 |
24 |
16.5 |
3.2 |
0.4 |
TF0240B |
GS55044-0240 |
PG440-0240 |
| GSF0250 |
25 |
17.5 |
2.2 |
0.4 |
TF050 |
GS55044-0250 |
PG440-0250 |
| GSFO250H |
25 |
14 |
4.2 |
0,8 |
TF0250B |
GS55042-0250 |
PG420-0250 |
| GSF0280 |
28 |
20.5 |
3.2 |
0.4 |
TF0280 |
GS55044-0280 |
PG440-0280 |
| GSFO280H |
28 |
17 |
4.2 |
0.8 |
TF0280B |
GS55042-0280 |
PG420-0280 |
| GSF0300 |
30 |
22,5 |
3.2 |
0.4 |
TF030 |
GS55044-0300 |
PG440-0300 |
| GSFO300H |
30 |
19 |
4.2 |
0.8 |
TF0300B |
GS55042-0300 |
PG420-0300 |
| GSF0320 |
32 |
24.5 |
3.2 |
0.4 |
TF0320 |
GS55044-0320 |
PG440-0320 |
| GSFO320H |
32 |
21 |
4.2 |
0,8 |
TF0320B |
GS55042-0320 |
PG420-0320 |
| GSF0350 |
35 |
27.5 |
3.2 |
0.4 |
TF0350 |
GS55044-0350 |
PG440-0350 |
| GSFO350H |
35 |
24 |
4.2 |
0.8 |
TF0350B |
GS55042-0350 |
PG420-0350 |
| GSF0360 |
36 |
28,5 |
3.2 |
0.4 |
TF0360 |
GS55044-0360 |
PG440-0360 |
| GSFO360H |
36 |
25 |
4.2 |
0.8 |
3F0360B |
GS55042-0360 |
PG420-0360 |
| GSF0380 |
38 |
30.5 |
3.2 |
0.4 |
TF0380 |
GS55044-0380 |
PG440-0380 |
| GSFO380H |
38 |
27 |
4.2 |
0,8 |
TF0380B |
GS55042-0380 |
PG420-0380 |
| GSF0400L |
40 |
32.5 |
3.2 |
0.4 |
TF0400 |
GS55046-0400 |
PG460-0400 |
| GSF0400 |
40 |
28 |
4.2 |
0.8 |
TF0400B |
GS55044-0400 |
PG440-0400 |
| GSF0450L |
45 |
37,5 |
3.2 |
0.4 |
TF0450 |
GS55046-0450 |
PG460-0450 |
| GSF0450 |
45 |
34 |
4.2 |
0.8 |
TF0450B |
GS55044-0450 |
PG440-0450 |
| GSF0480L |
48 |
40.5 |
3.2 |
0.4 |
TF0480 |
GS55046-0480 |
PG460-0480 |
| GSF0480 |
48 |
37 |
4.2 |
0.8 |
TF0480B |
GS55044-0480 |
PG440-0480 |
| GSF0500 |
50 |
39 |
4.2 |
0.8 |
TF0500 |
GS55046-0500 |
PG440-0500 |
| GSFO500H |
50 |
34.5 |
6.3 |
1.2 |
TF0500B |
GS55044-0500 |
PG420-0500 |
| GSF0520 |
52 |
41 |
4.2 |
0.8 |
TF0520 |
GS55046-0520 |
PG440-0520 |
| GSFO520H |
52 |
36.5 |
6.3 |
1.2 |
TF0520B |
GS55044-0520 |
PG420-0520 |
| GSF0550 |
55 |
44 |
4.2 |
0.8 |
TF0550 |
GS55046-0550 |
PG440-0550 |
| GSFO550H |
55 |
39.5 |
6.4 |
1.2 |
TF0550B |
GR55044-0550 |
PG420-0550 | 产品号缸径槽底径槽宽R1GB/T15242,1-94代号通用编号DH9dh9L+0.2MaxB+LB+S
|
|
| GSF0560 |
56 |
45 |
4.2 |
0.8 |
TF0560 |
GS55044-0560 |
PG440-0560 |
| GSF0560H |
56 |
40.5 |
6.3 |
1.2 |
TF0560B |
GS55042-0560 |
PG420-0560 |
| GSF0600 |
60 |
49 |
4.2 |
0.8 |
TF0600 |
GS55044-0600 |
PG440-0600 |
| GSF0600H |
60 |
44.5 |
6.3 |
1.2 |
TF0600B |
GS55042-0600 |
PG420-0600 |
| GSF0630 |
63 |
52 |
4.2 |
0,8 |
TF0630 |
GS55044-0630 |
PG440-0630 |
| GSF0630H |
63 |
47,5 |
6,3 |
1,2 |
TF0630B |
GS55042-0630 |
PG420-0630 |
| GSF0640 |
64 |
53 |
4.2 |
0.8 |
TF0640 |
GS55044-0640 |
PG440-0640 |
| GSF0640H |
64 |
48.5 |
6.3 |
1.2 |
TF0640B |
GS55042-0640 |
PG420-0640 |
| GSF0650 |
65 |
54 |
4.2 |
0.8 |
TF0650 |
GS55044-0650 |
PG440-0650 |
| GSF065H |
65 |
49.5 |
6.3 |
1.2 |
TF0650B |
GS55042-0650 |
PG420-0650 |
| GSF0700 |
70 |
59 |
4.2 |
0,8 |
TF0700 |
GS55044-0700 |
PG440-0700 |
| GSF0700H |
70 |
54,5 |
6,3 |
1,2 |
TF0700B |
GS55042-0700 |
PG420-0700 |
| GSF0750 |
75 |
64 |
4.2 |
0.8 |
TF0750 |
GS55044-0750 |
PG440-0750 |
| GSF0750H |
75 |
59.5 |
6.3 |
1.2 |
TF0750B |
GS55042-0750 |
PG420-0750 |
| GSFO800L |
80 |
69 |
4.2 |
0.8 |
TF0800 |
GS55046-0800 |
PG460-0800 |
| GSF0800 |
80 |
64.5 |
6.3 |
1.2 |
TF0800B |
GS55044-0800 |
PG440-0800 |
| GSFO850L |
85 |
74 |
4.2 |
0.8 |
TF0850 |
GS55046-0850 |
PG460-0850 |
| GSF0850 |
85 |
69.5 |
6,3 |
1,2 |
TF0850B |
GS55044-0850 |
PG440-0850 |
| GSFO900L |
90 |
79 |
4.2 |
0.8 |
TF0900 |
GS55046-0900 |
PG460-0900 |
| GSF0900 |
90 |
74.5 |
6.3 |
1.2 |
TF0900B |
GS55044-0900 |
PG440-0900 |
| GSFO950L |
95 |
84 |
4.2 |
0.8 |
TF0950 |
GS55046-0950 |
PG460-0950 |
| GSF0950 |
95 |
79.5 |
6.3 |
1.2 |
TF0950B |
GS55044-0950 |
PG440-0950 |
| GSFiO00L |
100 |
89 |
4.2 |
0.8 |
TF1000 |
GS55046-1000 |
PG460-1000 |
| GSF1000 |
100 |
84.5 |
6,3 |
1,2 |
TF1000B |
GS55044-1000 |
PG440-1000 |
| GSF1050L |
105 |
94 |
4.2 |
0.8 |
TF1050 |
GS55046-1050 |
PG460-1050 |
| GSF1050 |
105 |
89.5 |
6.3 |
1.2 |
TF1050B |
GS55044-1050 |
PG440-1050 |
| GSFll00L |
110 |
99 |
4.2 |
0.8 |
TF1100 |
GS55046-1100 |
PG460-1100 |
| GSFll00 |
110 |
94,5 |
6.3 |
1.2 |
TF1100B |
GS55044-1100 |
PG440-1100 |
| GSFll50 |
115 |
99.5 |
6.3 |
1.2 |
TF1150 |
GS55044-1150 |
PG440-1150 |
| GSF1200 |
120 |
104,5 |
6.3 |
1.2 |
TF1200 |
GS55044-1200 |
PG440-1200 |
| GSF1250 |
125 |
109.5 |
6.3 |
1,2 |
TF1250 |
GS55044-1250 |
PG440-1250 |
| GSF1250H |
125 |
104 |
8,1 |
1,6 |
TF1250B |
GS55042-1250 |
PG420-1250 |
| GSF1300 |
130 |
114.5 |
6.3 |
1.2 |
TF1300 |
GS55044-1300 |
PG440-1300 |
| GSF1300H |
130 |
109 |
8.1 |
1.6 |
TF1300B |
GS55042-1300 |
PG420-1300 |
| GSF1350 |
135 |
119.5 |
6.3 |
1.2 |
TF1350 |
GS55O46-135O |
PG46O-135O |
| GSF1350 |
135 |
114 |
8.1 |
1.6 |
TF1350B |
GS55044-1350 |
PG440-1350 |
| GSF1400L |
140 |
124.5 |
6.3 |
1,2 |
TF1400 |
GS55046-1400 |
PG460-1400 |
| GSF1400 |
140 |
119 |
8,1 |
1,6 |
TF1400B |
GS55044-1400 |
PG440-1400 |
| GSF1450 |
145 |
124 |
8.1 |
1.6 |
TF1450B |
GS55044-1450 |
PG440-1450 | 产品号缸径槽底径槽宽R1GB/T15242,1-94代号通用编号DH9dh9L+0.2MaxB+LB+S
|
|
| GSF1500 |
150 |
129 |
8.1 |
1.6 |
TF1500B |
GS55044-1500 |
PG440-1500 |
| GSF1550 |
155 |
134 |
8.1 |
1.6 |
TF1550B |
GS55044-1550 |
PG440-1550 |
| GSF1600 |
160 |
139 |
8,1 |
1.6 |
TF1600B |
GS55044-1600 |
PG440-1600 |
| GSF1650 |
165 |
144 |
8.1 |
1.6 |
TF1650B |
GS55044-1650 |
PG440-1650 |
| GSF1700 |
170 |
149 |
8.1 |
1.6 |
TF1700B |
GS55044-1700 |
PG440-1700 |
| GSF1750 |
175 |
156 |
8,1 |
1.6 |
TF1750B |
GS55044-1750 |
PG440-1750 |
| GSF1800 |
180 |
159 |
8.1 |
1.6 |
TF1800B |
GS55044-1800 |
PG440-1800 |
| GSF1900 |
190 |
169 |
8.1 |
1.6 |
TF1900B |
GS55044-1900 |
PG440-1900 |
| GSF2000 |
200 |
179 |
8,1 |
1.6 |
TF2000B |
GS55044-2000 |
PG440-2000 |
| GSF2100 |
210 |
189 |
8,1 |
1.6 |
TF2100B |
GS55044-2100 |
PG440-2100 |
| GSF2200 |
220 |
199 |
8.1 |
1.6 |
TF2200B |
GS55044-2200 |
PG440-2200 |
| GSF2300 |
230 |
209 |
8,1 |
1.6 |
TF2300 |
GS55044-2300 |
PG440-2300 |
| GSF2400 |
240 |
219 |
8.1 |
1.6 |
TF2400 |
GS55044-2400 |
PG440-2400 |
| GSF2500 |
250 |
229 |
8.1 |
1.6 |
TF2500 |
GS55044-2500 |
PG440-2500 |
| GSF2600 |
260 |
239 |
8,1 |
1.6 |
TF2600 |
GS55044-2600 |
PG440-2600 |
| GSF2700 |
270 |
249 |
8.1 |
1.6 |
TF2700 |
GS55044-2700 |
PG440-2700 |
| GSF2750 |
275 |
254 |
8.1 |
1.6 |
TF2750 |
GS55044-2750 |
PG440-2750 |
| GSF2800 |
280 |
259 |
8,1 |
1.6 |
TF2800 |
GS55044-2800 |
PG440-2800 |
| GSF2900 |
290 |
269 |
8.1 |
1.6 |
TF2900 |
GS55044-2900 |
PG440-2900 |
| GSF3000 |
300 |
279 |
8.1 |
1.6 |
TF3000 |
GS55044-3000 |
PG440-3000 |
| GSF3100 |
310 |
289 |
8,1 |
1.6 |
TF3100 |
GS55044-3100 |
PG440-3100 |
| GSF3200 |
320 |
299 |
8.1 |
1.6 |
TF3200 |
GS55044-3200 |
PG440-3200 |
| GSF3300 |
330 |
305.5 |
8.1 |
1.6 |
TF3300B |
GS55044-3300 |
PG440-3300 |
| GSF3400 |
340 |
315.5 |
8,1 |
1.6 |
TF3400B |
GS55044-3400 |
PG440-3400 |
| GSF3500 |
350 |
325.5 |
8.1 |
1.6 |
TF3500B |
GS55044-3500 |
PG440-3500 |
| GSF3600 |
360 |
335.5 |
8.1 |
1.6 |
TF3600B |
GS55044-3600 |
PG440-3600 |
| GSF3700 |
370 |
345.5 |
8.1 |
1.6 |
TF3700B |
GS55044-3700 |
PG440-3700 |
| GSF3800 |
380 |
355.5 |
8.1 |
1.6 |
TF3800B |
GS55044-3800 |
PG440-3800 |
| GSF3900 |
390 |
365.5 |
8.1 |
1.6 |
TF3900B |
GS55044-3900 |
PG440-3900 |
| GSF4000 |
400 |
375.5 |
8,1 |
1.6 |
TF4009 |
GS55044-4000 |
PG440-4000 |
| GSF4100 |
410 |
385.5 |
8.1 |
1.6 |
TF4100 |
GS55044-4100 |
PG440-4100 |
| GSF4200 |
420 |
395.5 |
8.1 |
1.6 |
TF4200 |
GS55044-4200 |
PG440-4200 |
| GSF4300 |
430 |
405.5 |
8,1 |
1.6 |
TF4300 |
GS55044-4300 |
PG440-4300 |
| GSF4350 |
435 |
410.5 |
8.1 |
1.6 |
TF4350 |
GS55044-4350 |
PG440-4350 |
| GSF4400 |
440 |
415.5 |
8.1 |
1.6 |
TF4400 |
GS55044-4400 |
PG440-4400 |
| GSF4500 |
450 |
425.5 |
8.1 |
1.6 |
TF4500 |
GS55044-4500 |
PG440-4500 |
| GSF4600 |
460 |
435.5 |
8.1 |
1.6 |
TF4600 |
GS55044-4600 |
PG440-4600 |
| GSF4700 |
370 |
445.5 |
8.1 |
1.6 |
TF4700 |
GS55044-4700 |
PG440-4700 |
| GSF4800 |
480 |
455.5 |
8,1 |
1.6 |
TF4800 |
GS55044-4800 |
PG440-4800 | 产品号缸径槽底径槽宽R1GB/T15242,1-94代号通用编号DH9dh9L+0.2MaxB+LB+S
|
|
| GSF4900 |
490 |
465.5 |
8,1 |
1,6 |
TF4900 |
GS55044-4900 |
PG440-4900 |
| GSF5000 |
500 |
475.5 |
8.1 |
1,6 |
TF5000 |
GS55044-5000 |
PG440-5000 |
| GSF5100 |
510 |
485.5 |
8,1 |
1,6 |
TF5100 |
GS55044-5100 |
PG440-5100 |
| OSF5200 |
520 |
495.5 |
8,1 |
1,6 |
TF5200 |
GS55044-5200 |
PG440-5200 |
| GSF5300 |
530 |
505,5 |
8.1 |
1,6 |
TF5300 |
GS55044-5300 |
PG440-5300 |
| GSF5400 |
540 |
515.5 |
8,1 |
1,6 |
TF5400 |
GS55044-5400 |
PG440-5400 |
| GSF5500 |
550 |
525.5 |
8,1 |
1,6 |
TF5500 |
GS55044-5500 |
PG440-5500 |
| GSF5600 |
560 |
535.5 |
8.1 |
1.6 |
TF5600 |
GS55044-5600 |
PG440-5690 |
| GSF5700 |
570 |
545.5 |
8,1 |
1,6 |
TF5700 |
GS55044-5700 |
PG440-5700 |
| OSF5800 |
580 |
555.5 |
8,1 |
1,6 |
TF5800 |
GS55044-5800 |
PG440-5800 |
| GSF6000 |
600 |
575,5 |
8.1 |
1.6 |
TF6000 |
GS55044-6000 |
PG440-6000 |
| GSF6100 |
610 |
585,5 |
8,1 |
1,6 |
TF6100 |
GS55044-6100 |
PG440-6100 |
一、性能与用途
由一个抗磨的填充聚四氟乙烯（PTFE）环和O形橡胶密封圈组成。O形圈提供预紧力，可对PTFE方形环
的磨损起补偿作用。适用于液压缸活塞的密封，为双向密封。一般与导向环配套使用。孔径小于40的
规格， 应采用分体式沟槽。
二、材 质
PTFE+NBR，特殊情况下橡胶弹性体采用氟胶FKM。
三、工况条件
工作压力：0-40MPa；
往复速度：≤5m/s；
使用温度：O形圈为丁腈胶NBR时：-30～+120℃，氟胶FKM时：-20～+200℃；
工作介质：液压油、气、水（在磷酸酯液压油中选用氟胶）。
四、设计标准
本系列符合ISO 7425/1标准，符合GB/T15242.1-94及GB/T15242.3-94标准，可参照霞板公司GS55044
系列，Merkel公司OMK-MR系列及Parker公司OE系列。销售电话：0512-57763877 张小姐：15371898387 传真：0512-82092229 联系qq1613831998 网址：http://www.ksjcmp.com 地址：昆山震川西路 昆山胶成密封制品有限公司 |
